E60H20-100-3-N-24
- Shaft inner diameter : Ø20mm
- Max. response frequency : 300kHz
- Max. allowable revolution : 6000rpm
- Starting torque : Max. 150gf.cm(max. 0.0147N.m)
- Resolution : 100P/R
- Control output : NPN open collector
- Power supply : 12-24VDC ±5%(ripple P-P: max. 5%)
- Connection type : Radial cable type
- Protection structure : IP50
